A certified, passive fire barrier to limit the spread of flames and smoke

Fire-rated Roller Shutters

Overview

Fire Rated Roller Shutters provide a certified, passive fire barrier to limit the spread of flames and smoke in both indoor and indoor/outdoor environments

Designed for frequent use, these shutters automatically deploy upon activation of a fire detection system, helping protect people and property.

Certification

Tested in accordance with EN 1634-1
Classified according to EN 13501-2
Validated cycle test in accordance with C2 (>10,000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

Suitable for indoor and indoor/outdoor situations
Designed for frequent use
Mounting only possible on wall/opening
Permissible mounting surfaces include:
- Aerated concrete
- Sand-lime brick
- Concrete
- Masonry
- Fire-resistant steel construction

Construction & Standard Features

Door Leaf: Double-walled galvanised steel slats, 22 mm thickness
Operation:
- Gravity failsafe chain wheel drive 400V (incl. control box)
- Gravity failsafe tubular motor 230V (up to ±8 m², incl. control box)
Safety: External safety catch device
Signalling: Optical and acoustic
Cycle Durability: >10,000 cycles

Fire Resistance & Maximum Dimensions

Classification	Fire Resistance	Max Width	Max Height	Max Area
EW 60	60 minutes	9,000 mm	9,000 mm	± 56 m²
EW 90	90 minutes	9,000 mm	9,000 mm	± 18–29 m²
EW 120	120 minutes	9,000 mm	9,000 mm	± 14–25 m²

Optional Features

Application in indoor/outdoor situations up to wind class 5 (>1,000 Pa)
Roll/motor cover box, galvanised steel
Powder-coated galvanised steel parts in the RAL colour of choice
Side guides, brackets, and cover box in stainless steel INOX 304 or 316
Set of light curtains
Stand-alone smoke detector
Various switches
